Remote Control Industrial Transfer Cart
KPJ cable drum electric flat car is also more and more with the progress of technology, and with the progress of industry, the customization requirements of new trackless flat car are higher and higher. According to the required load configuration, the drive system and electrical appliances of the electric flat car of the cable drum mainly provide the power source and safety control and detection for the car. The whole car is very convenient in operation, low noise and flexible in operation. It can automatically stop in case of people and objects, which not only improves the work efficiency but also avoids potential safety hazards.
According to the needs of different environments and socio-economic forms, a vertical and horizontal KPJ cable drum electric flat car equipment that can replace manual, forklift and ground rail turntable has been accepted by our customers. This cable drum electric flat car equipment can automatically transport objects of different tonnage to places with narrow space and path in different sites and environments, and can shuttle freely in various sites and environments. At present, it is mainly used for the operation of various abrasives, and it can also be used in various three-dimensional warehouses with automatic procedures, It has gradually become a leading role in the current transportation equipment.
Remote Control Industrial Transfer Cart
Henan Remarkable Intelligent Technology Co., Ltd is a professional handling equipment company integrated intelligent R&D, design, manufacturing, sales as well as after-sales service. It specializes in producing electric transfer carts of various tonnages, handling equipment accessories, intelligent crane and crane accessories with professional design, development and manufacture of non-standard, intelligent electric transfer carts and handling robots. According to different power mode, the handling equipment products can be divided into six series including low-voltage track-powered, battery-powered, towline-powered, cable reel-powered, safe-trolley-line powered, and unpowered traction.
| Technical parameters for Cable reel powered electric transfer carts KPJ series |
| Model | KPJ-6t | KPJ-10t | KPJ-16t | KPJ-25t | KPJ-40t | KPJ-63t | KPJ-100t | KPJ-160t | KPJ-200t |
| Rated load (t) | 6 | 10 | 16 | 25 | 40 | 63 | 100 | 160 | 200 |
Countertop size
(mm) | Length | 3600 | 3600 | 4000 | 4500 | 5000 | 5600 | 6300 | 8000 | 8200 |
| Width | 2000 | 2000 | 2200 | 2200 | 2500 | 2500 | 2800 | 2800 | 3000 |
| Height | 550 | 550 | 600 | 650 | 700 | 850 | 900 | 1150 | 1250 |
| Speed(m/min) | 30 | 30 | 30 | 30 | 25 | 25 | 20 | 20 | 18 |
| Wheel base A(mm) | 2000 | 2200 | 2200 | 2500 | 2800 | 3200 | 3600 | 5000 | 5000 |
| Track medial distance C(mm) | 1435 | 1435 | 1435 | 1435 | 1635 | 1735 | 1850 | 2000 | 2000 |
| Wheel diameter(mm) | 300 | 300 | 400 | 400 | 500 | 600 | 700 | 700 | 700 |
| Bottom clearance(mm) | 50 | 50 | 50 | 60 | 60 | 60 | 60 | 70 | 70 |
Motor model / power
(Kw) | YZ132M1-6 | YZ132M2-6 | YZ160M1-6 | YZ160M2-6 | YZ160L-6 | YZ160M2-6 | YZ160L-6 |
| 2.2 | 3.7 | 5.5 | 7.5 | 11 | 2×7.5 | 2×11 |
| Power mode | Cable drum | AC380V | AC380V | AC380V |
| 3×2.5+1×1.5 | 3×4+1×2.5 | 3×6+1×4 |
| Recommended track model | 24kg/m | 24kg/m | 38kg/m | 43kg/m | QU80 | QU100 |
| Number of wheels | 4 | 8 |
| Maximum wheel Pressure (t) | 1.91 | 3.21 | 4.87 | 7.5 | 11.5 | 16.9 | 27.6 | 22.8 | 28.5 |
| Reference weight (t) | 3.4 | 3.72 | 4.2 | 6 | 8.5 | 11.4 | 15.2 | 25.5 | 31.5 |
